MAXX ARMOUR® range of aramid reinforced conveyor belting solutions can perform in very demanding applications. The unique advantages of being heat and corrosion resistant, low creep properties, exceptionally high strength to weight ratio, chemical resistant and fire retardant differentiates it from conventional conveyor belts.
Up to 50% reduction in belt weight for same strength class & upto 40% reduction in belt thickness
Up to 15% energy saving in loaded condition & up to 30% saving in no load condition
Superior rip, tear and impact resistance
Similar growth & creep properties
No corrosion, less maintenance, better tracking
Potentially lower installation cost in case of new installations
Up to 30% reduction in belt weight with up to 40% reduction in thickness for same strength class
Up to 15% energy saving in loaded condition & upto 30% saving in no load condition
Lighter & thinner construction reduces number of splice
Exceptional thermal stability, better chemical stability and better durability
Significantly lower elongation compared to EP/NN belts resulting in lesser take-up requirement
MAXX ARMOUR® range of conveyor belting solutions can be used for underground & overland applications at mines, ports, steel, cement and other industries for following applications: Long Haul Conveyors Pipe Conveyors | Feeder Conveyors | Stacker Reclaimers | Bucket Elevators
| Width : | Upto 2100 mm (84”), higher widths available on request |
| Ply : | Mono-ply |
| Belt Length Range : | Upto 750 M/3.5 M Roll Diameter |
| Carcass Variety Available: | Straight Warp made of DuPont Kevlar® |
| Belt Rating | Mono ply constructions in 500/1, 630/1, 800/1, 1000/1, 1250/1, 1600/1, 2000/1, 2500/1, 3150/1, 4000/1 |
| Rubber Cover Compounds : | Customized based on application |
| Top Cover Thickness : | 5mm & above |
| Bottom Cover Thickness : | 3mm & above |
| Edges : | Cut / Moulded |
| Splicing Method : | Hot Finger Splice / Oriental “O” Splice |
| Packing : | Steel/Pallet/Wooden Drum |
| In accordance with DIN & Oriental standards | |
