Several manufacturing processes involve heat generation or conveyance of hot material. We have with our vast experience in Industrial applications put together a unique array of MAXX SURYA® belts for conveying your hot material.
Variety of cover grades to choose from 100 Deg C to 400 Deg C
Easy to splice (We recommend using Oriental splicing kit)
Robust testing before dispatch of the product
MAXX SURYA® finds applications in the conveying of the following material
Clinker | Sinter | Fly ash | Asphalt/Hot mix | Metcoke | Foundry sand | Burnt Lime
| Common Widths : | 500 mm to 2600 mm (20” to 102”) for EP/NN | 800 mm to 2400 mm (32″ to 94″) for ST |
| Carcass Variety Available : | EP /NN, MAXX ROCK®, MAXX ARMOUR®, MAXX STEELFLEX® |
| Common Belt Rating : | 200 to 3150 kN/m (110 to 1800 PIW) | ST500 to ST7500 kN/m (430 to 6420 PIW) |
| No. of Plies : | 2 ply to 7 ply |
| Rubber Cover Compounds : | Refer table for detailed properties |
| Rubber Cover Thickness : | 1.5 mm to 25 mm (1/16” to 1”) |
| Edge : | Cut/Moulded Edge |
| Splicing Method : | Hot/Mechanical recommended |
| Belt Identification : | Unique Product Identification Number (PIN) at every 10 Mtr (33’) |
